| Place of Origin: | Dongguan , China (Mainland) |
| Brand Name: | AOWA |
| Certification: | CCC |
| Model Number: | DM-QG |
Description:
Place of Origin: Dongguan, China (Mainland)
Power: 800W - 1200W
Voltage: 48V
Charging Time: 4-6hours
Foldable: No
Range Per Charge: 50km-60km
Tire Size: 14''x3.0 Tubeless tire
Specifications
| Electric System | |
| Motors available: | 800W - 1200W |
| Battery: | Lead-acid battery 12V / 20Ah X 4pcs |
| Controller: | 48V 35A limited;15 tubes(1200W) |
| Charger: | Smart Charger included,110V-240V |
| Performance | |
| Charging time: | ≥350 times |
| Recharging cycles: | 4h - 6h |
| Max speed: | 50km/h |
| Driving distance per charge: | 50km - 60km |
| Loading capacity: | 150kg |
| Climbing capacity: | 15 degrees |
| Main Components | |
| Frame: | Steel frame |
| Drive: | Direct hub motor drive |
| Brakes: | Front and rear colorful disc brake |
| Handle bar: | Right: throttle/front brake bar; left: rear brake bar |
| Suspension: | Hydraulic absorber |
| Meter: | LED screen, Battery/speed/turning signal/distance |
| Crank&Pedals: | No |
| Wheels: | Aluminium alloy rim |
| Wheel base: | 1310mm |
| Tires: | 14x3.2 Tubeless Tire |
| Dimension: | 1730*660*1100mm |
| Packing | |
| G.W.: | 114kg |
| N.W.: | 96kg |
| Packing: | Iron packing frame with Carton |
| Carton size: | 1700*600*900mm |
| Container loading QTY: | 26units/20'GP, 81units/40'HQ |
