| Place of Origin: | Zhejiang |
| Brand Name: | CHAOWEI |
| Certification: | CE, UL, CCC |
| Model Number: | BN3610AB |
Quick Details
Features
| Modularized design and pefectly compatible to the electric bicycles which are using traditional VRLA batteries |
| 'Green " and environment-friendly, no pollution to the environment during production and normal usage |
| Stable structure and simplified production process enables mass production and easy maintenance |
| Completely new protection design of water-proof, fire-proof, shock-resistance enable high safety |
| Professional protection module and BMS ensures the battery pack to be protected perfectly |
| High weight and measurement specific energy ensures the battery pack extremely long-voyage ability |
| Super long life supported by innovative technologies, high quality material and strict manufacturing control |
Applications
1. Electric Bicycle and Scooter
2. Electric Tricycles and electric vehicles
Specifications
|
Battery Model No. |
BN3610AB |
|
|
Material |
MnNiCo Ternary Material + LiMn2O4 |
|
|
Nominal Voltage (V) |
36V |
|
|
Nominal Capacity (C2, 25℃ ) |
10Ah |
|
|
Battery Pack Dimension (mm) |
390mm X 106mm X 76mm (L X W X H) |
|
|
Nominal Weight (Kg) |
3.4 Kgs ± 0.1 |
|
|
Continuous Charge Current (A) |
2A - 4A |
|
|
Charge Time (hr) |
3h - 6h |
|
|
Discharge Cut-off Voltage (V) |
≥ 30V |
|
|
Continuous Discharge Current (A) |
≤ 10A |
|
|
Pulse Discharge Current (A) |
≤ 15A |
|
|
Cycle Life at80% D.O.D. |
≥ 1200 Cycles |
|
|
Capacity Retention Rate at 0℃ |
≥ 90% |
|
|
Self-Discharge Rate (25℃) |
≤ 5% per month |
|
|
Temperature Characteristic |
Charging |
-20℃ - 40℃ |
|
Discharging |
-20℃ - 40℃ |
|
|
Storage |
-20℃ - 40℃ |
|
